8 Inch Round Ceiling Speakers 100V 70V Iron Ceiling PA Loudspeaker

Place of Origin : Guangdong, China

Model Number : CL-348B

MOQ : 100

warranty : 3years

dimension : 270*190

power source : Other

output power : 40/20/10/5W/8ohm

Shell Material : Iron

the body material : Metal

Radio function : NO

Operating Voltage : 100V, 70V

Impedance : 8ohm

Frequency response : 90-20KHz

Magnet Material : Ferrite, Neodymium

Contact Now

8 Inch Round Ceiling Speakers 100V 70V Iron Ceiling PA Loudspeaker

Product Description

CL-348B Ceiling Speaker: Premium Audio for Professional Spaces

Features:
1. Design & Build Quality
The CL-348B is a high-end coaxial ceiling speaker engineered for commercial and industrial environments. It features an 8-inch coaxial speaker unit, combining precision sound reproduction with durable construction. The housing uses a white metal grille, ABS baffle, and metal back cover, ensuring both aesthetic appeal and long-term reliability. With product dimensions of 270×190 mm and a weight of 3.1 kgs, it supports secure flush-mount installation—ideal for integrating into hotels, offices, factories, and public spaces requiring background music or paging.
2. Audio Performance & Flexibility
Equipped with a built-in 100V/70V/8ohm transformer, the CL-348B minimizes line losses over long distances, enabling seamless parallel connection of multiple speakers in large-scale setups. A standout feature is its rotatable eyeball tweeter: users can tilt the tweeter to adjust the sound dispersion angle, directing audio precisely to the target area for optimized coverage. In terms of power, it delivers flexible output options (40/20/10/5W at 100V/70V, 8W at 8ohm) and boasts a 90dB sensitivity. The frequency range of 90–20KHZ ensures rich bass, clear midrange vocals, and detailed highs—perfect for reproducing music, announcements, or ambient sound with exceptional fidelity.
3. Application Suitability
This speaker excels in commercial environments where audio quality and adaptability matter. In hotels, it provides refined
background music for lobbies and guest areas; in offices, it supports clear paging and audio reinforcement; in factories, it
ensures reliable sound distribution over large spaces. The CL-348B balances professional-grade performance, flexible installation, and stylish design design, making it a top choice for projects demanding both functionality and sonic excellence.

Model	Speaker Size	Power	Voltage	Sensitivity	Frequency Response	Dimension(mm)	Material	Mounting Hole
CL-345B	5" Coaxial Speaker	20/10/5/2.5/8ohm	100V/70V	88DB	100-20KHz	203*150	Iron	170
CL-346B	6" Coaxial Speaker	30/15/7.5/3.8W/8ohm	100V/70V	89DB	100-20KHz	230*155	Iron	200
CL-348B	8" Coaxial Speaker	40/20/10/5W/8ohm	100V/70V	90DB	90-20KHz	270*190	Iron	240
